The vacuum system must consist of the correct components according to the milking parlour capacity and it is features.
Our own produced vacuum system components are always with the same performance one time ready for your use; even in all hard condition.
Vacuum pumps; milking parlours hearth
We are providing vacuum pumps for every capacity and different milking parlours features that much your need.
It will serve you for years without causing any problems during your milking operations, under all hard-working conditions.
Average Vacuum Pump (VP) Electrik Motor (EM) EM RPM VP RPM EM Pulley VP Pulley Reserve Tank
Capacity (50 kPa) (1/min) Power (kW) (1/min) (1/min) Diameter (mm) Diameter (mm) Volume (I)
VP200 200 0.75 1400 1400 Coupled Coupled 18
VP240 240 1.1 1400 1400 Coupled Coupled 18
VP400 400* 1.5 1415 1639 130 110 35
VP600 600* 1.5 1420 1624 140 120 35
VP900 900* 2.2 1440 1646 140 120 35
VP1200 1200 3 1440 1646 140 120 35
VP1600 1600 4 1448 1528 140 130 90
VP2000 2000 5.5 1448 1528 140 130 90
VP2500 2500 5.5 1455 1426 140 140 90
VP3300 3300 5.5 1455 1110 140 180 125
